KTM 990 SMR Service Repair Manual / 2013

KTM 990 Supermoto R SMR Service Repair Manual / 2013 PDF Download
Repair Manual 2013 for Models:
990 Supermoto R EU
990 Supermoto R FR
990 Supermoto R AUS/UK
Article no. 3206155en
File type: PDF
File pages: 295

2013 KTM 990 Supermoto R - specs
Water cooled, 999cc, 75° V-twin, DOHC
Power: 115.57 HP (85 kW)
Final drive: Chain
Curb weight: 192 kg
Category: Supermoto
Presented motorcycle KTM 990 Supermoto R by year 2013 like many motorcyclists. On this page we have tried to collect the information and quality images KTM 990 Supermoto R 2013 that can be saved or downloaded to your device. Also pay attention to the other series of the motorcycle, for example, 2013, 2011.

KTM 990 SMT Service Repair Manual / 2013

KTM 990 Supermoto T SMT Service Repair Manual / 2013 PDF Download
Repair Manual 2013 for Models:
990 Supermoto T EU
990 Supermoto T FR
990 Supermoto T AUS/UK
990 Supermoto T USA
Article no. 3206160en
File type: PDF
File pages: 302

2013 KTM 990 SMT –  USA Specifications/Technical Details
ENGINE
Design 2-cylinder 4-stroke Otto motor, 75° V arrangement, water-cooled
Displacement 999 cm³ (60.96 cu in)
Bore 101 mm (3.98 in)
Stroke 62.4 mm (2.457 in)
Performance 85 kW (114 hp)
Cold start device Electric starter
Transmission 6-gears, claw-shifted
Engine lubrication Dry sump lubrication system with two rotor pumps
Primary transmission 35:67
Secondary drive ratio 17:41
Cooling Water cooling, permanent circulation of coolant by water pump
Clutch Multidisc clutch in oil bath/hydraulically activated
Ignition system Contactless controlled fully electronic ignition with digital ignition adjustment
CHASSIS
Frame Lattice frame made of chrome molybdenum steel tubing, powder-coated
Fork WP Suspension Up Side Down
Shock absorber WP Suspension Monoshock
Suspension travel Front 160 mm (6.3 in)
Suspension travel Rear 180 mm (7.09 in)
Brake system Front Double disc brake with radially screwed four-piston brake calipers, float-mounted brake discs
Brake system Rear Single disc brake with dual-piston brake caliper, rigid-mounted brake disc
Brake discs – diameter Front 305 mm (12.01 in)
Brake discs – diameter Rear 240 mm (9.45 in)
Chain 5/8 x 5/16″ X ring
Steering head angle 65.6°
Wheelbase 1,505±15 mm (59.25±0.59 in)
Ground clearance, unloaded 195 mm (7.68 in)
Seat height, unloaded 855 mm (33.66 in)
Total fuel tank capacity, approx. 19 l (5 US gal)
Super unleaded (ROZ 95/RON 95/PON 91)
Weight without fuel, approx. 197 kg (434 lb.)

KTM 690 SMC R Service Repair Manual / 2013

KTM 690 SMC R Service Repair Manual / 2013 PDF Download
Repair Manual 2013 for Models:
690 SMC R EU
690 SMC R AUS/UK
Article no. 3206153en
File type: PDF
File pages: 230

The motorcycle rewards you with first class ergonomics and you’ll especially like the self-supporting rear end/fuel tank unit and the low seat. Not to mention about the sporty stance and the perfectly angled, wide aluminum handlebar.

The bike is equipped with a lightweight tubular space frame made from chrome-molybdenum steel. The frame is combined with a high-quality die-cast swingarm which is ultra resistant to torsion.

The ride quality is assured by the KTM 690 SMC R’s WP upside-down fork, which offers a whole 250 mm of suspension travel and 48 mm outer tubes. Out back, you’ll find a pivot-arm articulated WP pressurised-gas monoshock which offers 250 mm of wheel travel. If you want to bring the bike to halt, you can rely with confidence on a set of capable Brembo brakes.

KTM 690 Enduro R Service Repair Manual / 2013

KTM 690 Enduro R Service Repair Manual / 2013 PDF Download
Repair Manual 2013 for Models:
690 Enduro R EU
690 Enduro R AUS/UK
690 Enduro R USA
Article no. 3206150en
File type: PDF
File pages: 234

2013 KTM 690 Enduro R – USA Specifications/Technical Details
ENGINE
Design 1-cylinder 4-stroke engine, water-cooled
Displacement 690 cm³ (42.11 cu in)
Bore 102 mm (4.02 in)
Stroke 84.5 mm (3.327 in)
Starting aid Electric starter, automatic decompressor
Performance 49 kW (66 hp)
Gearbox 6-gears, claw-shifted
Engine lubrication Pressure circulation lubrication with two rotor pumps
Primary transmission 36:79
Secondary drive ratio 15:45
Cooling Water cooling, permanent circulation of coolant by water pump
Clutch APTC™ Antihopping clutch in oil bath/hydraulically operated
Ignition Contactless controlled fully electronic ignition with digital ignition adjustment
CHASSIS
Frame Lattice frame made of chrome molybdenum steel tubing, powder-coated
Fork WP Suspension 4860 D48/26 MA
Shock absorber WP Suspension 4618 with Pro Lever deflector
Suspension travel Front 250 mm (9.84 in)
Suspension travel Rear 250 mm (9.84 in)
Brake system Front Disc brake with dual-piston brake caliper, floating
Brake system Rear Disc brake with single-piston brake caliper, floating
Brake discs – diameter Front 300 mm (11.81 in)
Brake discs – diameter Rear 240 mm (9.45 in)
Chain 5/8 x 1/4″ X ring
Steering head angle 63°
Wheelbase 1,504±15 mm (59.21±0.59 in)
Ground clearance unloaded 280 mm (11.02 in)
Seat height unloaded 910 mm (35.83 in)
Total fuel tank capacity, approx. 12 l (3.2 US gal)
Super unleaded (ROZ 95/RON 95/PON 91)
Weight without fuel, approx. 138.5 kg (305.3 lb.)

KTM DUKE 690 Service Repair Manual / 2013

KTM DUKE 690 / 690 R Service Repair Manual 2013 PDF Download
Repair Manual 2013 for Models:
690 Duke EU
690 Duke AUS/UK
690 Duke USA
690 Duke MAL
690 Duke R EU
690 Duke R AUS/UK
690 Duke R MAL
Article no. 3206164en
File type: PDF
File pages: 263

2013 KTM 690 Duke – USA Specifications/Technical Details
ENGINE
Design Single-cylinder, 4-stroke, spark-ignition engine, liquid-cooled
Displacement 690 cm³
Bore 102 mm
Stroke 84.5 mm
Performance 50 kW (67 hp)
Starting aid Electric starter, automatic decompressor
Transmission 6-speed, claw shifted
Engine lubrication Semi-dry-sump lubrication with 2 rotor pumps
Primary gear ratio 36:79
Secondary gear ratio 16:40
Cooling system Liquid cooling system, continuous circulation of cooling liquid with water pump
Clutch APTC™ Anti-hopping clutch / hydraulically operated
Ignition system Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
CHASSIS
Frame Tubular space frame made from chrome molybdenum steel, powder-coated
Fork WP Suspension Up Side Down
Shock absorber WP Suspension with Pro Lever linkage
Suspension travel front 135 mm
Suspension travel rear 135 mm
Brake system front Disc brake with radially mounted four-piston brake caliper
Brake system rear Disc brake with single-piston brake caliper, floating
Brake discs – diameter front 320 mm
Brake discs – diameter rear 240 mm
Chain 5/8 x 1/4″ X Ring
Steering head angle 63.5°
Wheel base 1,466±15 mm
Ground clearance (unloaded) 192 mm
Seat height (unloaded) 835 mm
Total fuel tank capacity approx. 14 l
Unleaded premium fuel (95 RON)
Weight without fuel approx. 149.5 kg

KTM 250 EXC-F XCF-W Repair Manual / 2013

KTM 250 EXC-F XCF-W Repair Manual / 2013 PDF Download
Repair Manual 2013 fit models:
250 EXC-F EU
250 EXC-F AUS
250 EXC-F SIX-DAYS EU
250 XCF-W USA
Art. no. 3206151en
File type: PDF
File pages: 290

2013 KTM 250EXC-F REVIEW
It’s an unbelievable handling miracle. It’s ridden to countless world titles! The KTM 250 EXC-F. Our absolute success story. Builds up plenty of traction at the bottom of the rev range and pushes hard at the top. And the story continues in 2013! Factory rider Antoine Meo is entering into battle for this year’s world championship title in the E2 class on the latest version. The new model excels with its super-agile chassis thanks to state-of-the-art WP suspension components and its powerful DOHC engine featuring electronic fuel injection. And by the way, the new model comes in an extremely sporty outfit.

KTM 250 SX XC / 300 XC Repair Manual / 2013

KTM 250 SX XC / 300 XC Repair Manual / 2013 Download PDF
Repair Manual 2013 fit models:
250 SX EU
250 SX USA
250 XC EU/USA
300 XC EU/USA
Art. no. 3206176en
File type: PDF
File pages: 277

2013 KTM 300XC – USA Specifications/Technical Details
ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake and exhaust control
Displacement 293 cm³ (17.88 cu in)
Bore 72 mm (2.83 in)
Stroke 72 mm (2.83 in)
Starting aid Kick starter and electric starter
Gearbox 6-gear, claw shifted
Primary transmission 26:72
Secondary ratio 14:50
Clutch Multidisc clutch in oil bath/hydraulically activated
Ignition Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan
CHASSIS
Frame Central tube frame made of chrome molybdenum steel tubing
Fork WP Suspension Up Side Down 4860 MXMA CC
Shock absorber WP Suspension 5018 BAVP DCC
Suspension travel Front 300 mm (11.81 in)
Suspension travel Rear 317 mm (12.48 in)
Brake system Disc brakes, brake calipers on floating bearings
Brake discs – diameter Front 260 mm (10.24 in)
Brake discs – diameter Rear 220 mm (8.66 in)
Chain 5/8 x 1/4″
Steering head angle 63.5°
Wheelbase 1,495±10 mm (58.86±0.39 in)
Ground clearance unloaded 385 mm (15.16 in)
Seat height unloaded 992 mm (39.06 in)
Total fuel tank capacity, approx. 11.5 l (3.04 US gal)
Super unleaded gasoline, mixed with 2-stroke engine oil (1:60)
Weight without fuel, approx. 104 kg (229 lb.)

KTM 250 EXC XC-W / 300 EXC XC-W Repair Manual / 2013

KTM 250 EXC XC-W / 300 EXC XC-W Repair Manual / 2013 PDF DownloadRepair Manual 2013 fit models:
250 EXC EU
250 EXC SIX DAYS EU
250 EXC AUS
250 XC-W USA
300 EXC EU
300 EXC SIX DAYS EU
300 EXC AUS
300 XC-W USA
Art. no. 3206170en
File type: PDF
File pages: 270

2013 KTM 300XCW – USA Specifications/Technical Details
ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake and exhaust control
Displacement 293 cm³ (17.88 cu in)
Bore 72 mm (2.83 in)
Stroke 72 mm (2.83 in)
Starting aid Kick starter and electric starter
Gearbox 6-gear, claw shifted
Primary transmission 26:72
Secondary ratio 13:50
Clutch Multidisc clutch in oil bath/hydraulically activated
Ignition Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan
CHASSIS
Frame Central tube frame made of chrome molybdenum steel tubing
Fork WP Suspension Up Side Down 4860 MXMA PA
Shock absorber WP Suspension PDS 5018 DCC
Suspension travel Front 300 mm (11.81 in)
Suspension travel Rear 335 mm (13.19 in)
Brake system Disc brakes, brake calipers on floating bearings
Brake discs – diameter Front 260 mm (10.24 in)
Brake discs – diameter Rear 220 mm (8.66 in)
Chain 5/8 x 1/4″
Steering head angle 63.5°
Wheelbase 1,482±10 mm (58.35±0.39 in)
Ground clearance unloaded 355 mm (13.98 in)
Seat height unloaded 960 mm (37.8 in)
Total fuel tank capacity, approx. 10 l (2.6 US gal)
Super unleaded gasoline, mixed with 2-stroke engine oil (1:60)
Weight without fuel, approx. 102 kg (225 lb.)

KTM 125 Duke Pips Yamaha MT-15 On The Sales Chart

The baby Duke has added another feather to its cap, overtaking the MT-15 on the sales chart for the first time

• KTM sold 2,228 units of the 125 Duke in the month of May.
• Yamaha sold 2,048 units in the same time.
• While the KTM 125 Duke is priced at Rs 1.30 lakh, the MT-15 retails at Rs 1.36 lakh.

Since its launch, the MT-15 has been raking in some good numbers for Yamaha. In the process, it has constantly overtaken its rival, the 125 Duke. However, for the first time in the past few months, the 125 Duke has finally pipped the MT-15 in terms of sales.

Also read: KTM’s Baby Supersport, The RC 125, Launched In India

The Austrian bike maker sold 2,228 units of the baby Duke, compared to 2,048 units of the MT-15 in the month of May. Yes, this isn’t that big of a difference, but this shows us how popular the baby Duke is. But the coming months could be a testing time for the Austrian bike maker, as the 125 Duke has seen several price hikes in the past few months, which could affect its sales. On the other hand, Yamaha is trying to increase footfalls in its showrooms. The company had recently announced that existing and new MT-15 customers will get a complimentary riding jacket or a helmet.

Given how things are positioned right now, it will be interesting to watch the KTM 125 Duke and Yamaha MT-15 rivalry over the next few months.

KTM 125 SX / 150 SX XC Repair Manual / 2013

KTM 125 SX / 150 SX XC Repair Manual / 2013
 Repair Manual 2013 fit models:
125 SX EU
125 SX USA
150 SX EU
150 SX USA
150 XC USA
Art. no. 3206174en
File type: PDF
File pages: 235

Motocross – The current Motocross line designated by SX includes 50, 65, 85, 105, 125, 150 and 250 cc single-cylinder two-stroke models (the 50 SX, 65 SX and 85 SX models are kids' and youth bikes), and 250, 350 and 450 cc single-cylinder four-stroke models (SX-F). In 2005 KTM released the new 250SX-F to the general public. Since 2007, the SX-F's have been KTM's new racing motocross range. Current versions of the KTM SX-F line have a dual overhead camshaft engine dubbed the “RC4”.

KTM 125 EXC / 200 EXC XC-W Repair Manual / 2013

KTM 125 EXC / 200 EXC XC-W Repair Manual / 2013
 Repair Manual 2013 fit models:
125 EXC EU
125 EXC SIX DAYS EU
200 EXC EU
200 EXC AUS
200 XC-W USA
Art. no. 3206136en
File type: PDF
File pages: 292

Enduro – The street-legal EXC enduro versions of KTM's XC cross-country bikes are supplied with plusher non-linkage suspensions, a wider-ratio gear box and lights.

KTM DUKE 125 / DUKE 200 Repair Manual / 2013

KTM DUKE 125 / DUKE 200 Repair Manual / 2013 Download
 Repair Manual 2013 fit models:
125 Duke EU
200 Duke EU
200 Duke MAL
200 Duke AR
200 Duke 2014 COL
Art. no. 3206162en
File type: PDF
File pages: 291

The KTM 200 Duke is a standard or "naked" motorcycle made by KTM and sold in most markets worldwide. It has a single-cylinder, four-stroke, spark-ignition liquid-cooled engine. It has six-speed gearbox with the gear ratios and a cable actuated multi-disc clutch. The bike has an underbelly exhaust and a three-chamber silencer positioned close to its centre of gravity.

The Duke 200 is manufactured at Bajaj Autos Chakan Plant in India. In Colombia, it is being assembled by the company Auteco S.A. In Argentina, is being assembled by the company Simpa S.A. since March 2014. In the Philippines, it is being assembled by the company KTM Asia Motorcycle Manufacturing, Inc. (KAMMI) in Sta. Rosa, Laguna.

KTM 1190 RC8 R RC8R Repair Manual / 2013

KTM 1190 RC8 R RC8R Repair Manual 2013 PDF Download
1190 RC8 R EU/UK
1190 RC8 R FR
1190 RC8 R JP
1190 RC8 R USA
Article no. 3206158en
File type: PDF
File pages: 305

2013 KTM 1190RC 8R Features and Benefits

– Highly developed LC8 V-Twin with optimised crankshaft, carefully balanced flywheel masses and dual-plug ignition, max. output 175 PS, max. torque 127 Nm
– Perfectly tuned suspension
– Rear linkage with eccentric bracket for ride height and anti-squat adjustment
– Radial Brembo four-pot monoblock callipers on reinforced 320 mm discs
– LED daytime running lights
– Great OEM tires: the first-rate Dunlop SportSmart
– Control and riding position ergonomics with comprehensive adjustments
– Multi-functional display
– Available in White/Orange and Black/Orange, both with orange wheels and frame

ENGINE 2-CYLINDER, 4-STROKE ENGINE V 75° · DISPLACEMENT 1195 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 16.5L
WEIGHT (READY TO RACE) APPROX. 182 KG (WITHOUT FUEL

KTM 1190 Adventure Repair Manual / 2013

KTM 1190 Adventure Repair Manual / 2013 Download
Repair Manual 2013:
1190 Adventure R EU
1190 Adventure R AUS
1190 Adventure R FR
1190 Adventure R JP
Art. no. 3206173en
File type: PDF
File pages: 306

KTM 1190 Adventure

Manufacturer	KTM
Production	2013–2016
Predecessor	990 Adventure
Successor	1290 Super Adventure
Class	Adventure touring
Engine	1195 cc, 8-valve, 75° V-twin
Bore / stroke	105mm_69mm
Power	148 hp (110 kW)
Torque	92.2 ft⋅lb (125.0 N⋅m)
Ignition type	double ignition
Transmission	6-speed,PASC (TM) slipper clutch, hydraulically actuated, chain drive
Frame type	Steel tube trellis
Suspension	Front: 48 mm WP fork with adjustable rebound and compression Rear: WP shock with adjustable preload, compression and damping Optional electronic damping control
Brakes	Front: Dual 320 mm disc; Brembo 4-pot caliper Rear: Single 260 mm disc; 2-pot caliper Semi-linked ABS
Tires	Front: 120/70/R19" Rear: 170/60/R17"
Rake, trail	26°
Wheelbase	61.4 in (1,560 mm)
Seat height	890 mm (35 in)
Weight	467 lb (212 kg) (dry)
Fuel capacity	6.1 US gal (23 l)

KTM 1190 Adventure R Repair Manual / 2013

KTM 1190 Adventure R Repair Manual / 2013 Download
Repair Manual 2013:
1190 Adventure R EU
1190 Adventure R AUS
1190 Adventure R FR
1190 Adventure R JP
Art. no. 3206161en
File type: PDF
File pages: 303

The KTM 1190 Adventure is a 1195 cc V-twin adventure touring motorcycle from the Austrian manufacturer KTM. The model was revealed at the October 2012 Intermot trade show for the 2014 model year.

The LC8 motor is based on the powerplant in the RC8 sportbike. Like the RC8, and unlike its predecessor the 990 Adventure, the 1190 Adventure uses ride-by-wire throttle. Cycle World and Motor Cycle News noted the electronic rider aids including ride-by-wire and electronic suspension control, up until now foregone by KTM to emphasize off-road performance, are intended to position the 1190 Adventure against technologically advanced street-going rivals like the Ducati Multistrada 1200. It is the first bike with Bosch's Anti-Lowside Technology, the so-called Motorcycle Stability Control (MSC).

KTM beats Harley Davidson in sales – Now aims to overtake Kawasaki

KTM AG, the Austrian motorcycle company, owned jointly by KTM Industries AG and Bajaj Auto Limited, is on the brink of entering the list of top three bikes makers of full sized motorcycles. The company which has surpassed Harley Davidson Inc as the leading motorcycle maker outside of Asia, has now trained its sights on scaling past Kawasaki Motors.

Stefan Pierer is at the helm of KTM after having taken over in 1991 and is there to this day 28 years later. He has steered the company to great heights allowing the Austrian manufacturer to surpass Harley Davidson, outdoing the latter in terms of sales in 2018 after selling 2,61,000 motorcycles globally overtaking Harley by approximately 35,000 units.

KTM sales have quadrupled in what is seen as a shrinking two wheeler market. The company has introduced new designs and is paying extra attention to Asia. The company now targets sales of 4,00,000 units by 2022 which means they will soon overtake Kawasaki Motors on the sales charts in their race to break into the top three motorcycle manufacturers.

KTM is still behind Piaggio Group in Europe in terms of sales. In the past year, the leading bikemaker Honda Motors sold 20 million two wheelers while in a second spot, Yamaha Motor’s sales stood at 5.4 million. It will not be smooth for KTM to reach at the top.

But with market dynamics changing, thanks to stricter emission norms and shift to EV tech; Pierer states that the company would have to concentrate more on electric bikes in the future so as to allow the company to compete at a global level.

Where electric two wheelers are concerned, KTM and Bajaj Auto have initiated a project called PTW – Powered Two Wheelers. Under this project, the two automakers will jointly develop electric two wheelers in India with production to commence at the Bajaj plant in Pune by 2022. The development includes a 48 volt electric platform having power outputs of 3Kw (4PS) to 10Kw (13PS) and a budget has already been allocated for the same.

This platform will be used for electric scooters, mopeds and small mopeds and will be used by Bajaj and KTM for their range of electric vehicles. This joint development will benefit both the automakers. KTM will benefit from Bajaj Auto’s experience in low cost manufacture while Bajaj Auto will gain from KTMs earlier endeavours in the electric two wheeler segment. Bajaj is all set to launch its first electric bike under the Urbanite brand later this year, as the e-scooter has been spied testing.

KTM already sells electric two wheelers in some global markets one of which is called the KTM e-Ride. This bike offers peak power output of 18 kW which is much higher than that which will be offered by other electric two wheelers set to be produced in India.

KTM 1190 RC8 R RC8R Repair Manual / 2012

2012 KTM 1190 RC8R Features and Benefits
– Highly developed LC8 V-Twin with optimised crankshaft, carefully balanced flywheel masses and dual-plug ignition, max. output 175 PS, max. torque 127 Nm
– Perfectly tuned suspension
– Rear linkage with eccentric bracket for ride height and anti-squat adjustment
– Radial Brembo four-pot monoblock callipers on reinforced 320 mm discs
– LED daytime running lights
– Great OEM tires: the first-rate Dunlop SportSmart
– Control and riding position ergonomics with comprehensive adjustments
– Multi-functional display
– Available in White/Orange and Black/Orange, both with orange wheels and frame

ENGINE 2-CYLINDER, 4-STROKE ENGINE V 75° · DISPLACEMENT 1195 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 16.5L
WEIGHT (READY TO RACE) APPROX. 182 KG (WITHOUT FUEL

KTM 1190 RC8 R RC8R Repair Manual 2012 PDF Download
1190 RC8 R EU/UK
1190 RC8 R FR
1190 RC8 R JP
1190 RC8 R USA
Article no. 3206117en
File type: PDF
File pages: 305

KTM DUKE 125 Service Repair Manual / 2012

KTM DUKE 125 Service Repair Manual 2012 PDF Download
Repair Manual 2012 for Models:
125 Duke EU
125 Duke DE
200 Duke EU
200 Duke 2013 COL
Article no. 3206127en
File type: PDF
File pages: 267

2012 KTM 125 Duke Features and Benefits
– Extremely powerful 1-cylinder, 4-stroke DOHC engine, electronic fuel injection, 3-way catalytic converter, balancer shaft,
max. output: 11 kW/15 PS
– Ultra-light die-cast aluminium swingarm
– Powerful braking system developed in co-operation with Brembo
– Comprehensive multi-functional cockpit
– Optional electronic restriction to 80km/h
– New, attractive colour scheme

ENGINE SINGLE CYLINDER, 4-STROKE · DISPLACEMENT 124.7 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 11L
WEIGHT (READY TO RACE) APPROX. 115 KG (WITHOUT FUEL)

KTM 990 SMT Supermoto T Service Repair Manual / 2012

KTM 990 SMT Supermoto T Service Repair Manual 2012 PDF Download
2012 Repair Manual Fit Models:
990 Supermoto T EU
990 Supermoto T AUS/UK
990 Supermoto T FR
990 Supermoto T USA
Article no. 3206159en
File type: PDF
File pages: 302

2012 KTM 990 SMT Features and Benefits
– Powerful LC8 4-stroke V-Twin, electronic K eihin fuel injection with two throttle valves, balancer shaft, hydraulic multi-disc wet clutch, 6-speed gearbox
– Max. output: 85 kW/116 PS, emissions: Euro 3
– Rigid, powder coated trellis frame welded from chrome-molybdenum steel sections, black aluminium swingarm
– Fully adjustable suspension front and rear
– New: Preload Adjuster on shock absorber
– Radial Brembo four-pot front callipers on floating brake discs
– Continental tires perfect for sport and touring
– Frame-mounted fairing with windshield and integrated multi-functional cockpit
– Comfortable stepped seat, luggage carrying system and hand guards
– Now with improved access to pre-load adjuster
– State-of-the-art Bosch ABS

ENGINE 2-CYLINDER, 4-STROKE, V 75° · DISPLACEMENT 999 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 19.0L
WEIGHT (READY TO RACE) APPROX. 196 KG (WITHOUT FUEL)

KTM 990 SMR Supermoto R Service Repair Manual / 2012

KTM 990 Supermoto R Service Repair Manual 2012 PDF Download
2012 Repair Manual Fit Models:
990 Supermoto R EU
990 Supermoto R AUS/UK
990 Supermoto R FR
Article no. 3206154en
File type: PDF
File pages: 295

2012 KTM 990 SMR Features and Benefits
– Powerful LC8 4-stroke V-Twin, electronic Keihin fuel injection with two throttle valves, balancer shaft, hydraulic multi-disc wet clutch, 6-speed gearbox
– Max. output: 85 kW/116 hp, emissions: Euro 3
– State-of-the-art Bosch 9M+ ABS
– Rigid, powder coated, chrome-molybdenum steel trellis frame with black aluminium swingarm
– Fully adjustable, 48 mm WP upside-down forks
– Fully adjustable WP monoshock
– New aluminium wheels with Continental hypersport tires
– Radial Brembo monoblock four-pot front callipers on floating brake discs
– Complex KTM R graphics
– Even tighter entry-level pricing thanks to optimised component tuning

ENGINE 2-CYLINDER, 4-TAKT. V 75° · DISPLACEMENT 999 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 15L
WEIGHT (READY TO RACE) APPROX. 192 KG (WITHOUT FUEL)

KTM 690 SMC R Service Repair Manual / 2012

KTM 690 SMC R Service Repair Manual 2012 PDF Download
Repair Manual 2012 for Models:
690 SMC R EU
690 SMC R AUS/UK
Article no. 3206126en
File type: PDF
File pages: 230

2012 KTM 690 SMCR Features and Benefits
– Powerful LC4 1-cylinder, 4-stroke engine with electronic fuel injection, balancer shaft, APTC anti-hopping clutch and 6-speed gearbox
– Max. output: 49 kW/67 hp, emissions: Euro 3
– Light steel trellis frame with innovative, die-cast swingarm and self-supporting polymer tail tank
– New, ergonomically optimised seat with increased comfort
– New, fully adjustable WP suspension with revised spring rates and optimised front/rear weight distribution for even greater agility
– High quality Brembo four-pot front brake system
– New Continental SportAttack SM tires with outstanding grip
– Tubeless wire wheels developed by KTM
– New, dynamic spoiler line
– Very low weight of only 139 kg

ENGINE SINGLE CYLINDER, 4-STROKE ENGINE · DISPLACEMENT 690CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 12L
WEIGHT (READY TO RACE) APPROX. 139.5 KG (WITHOUT FUEL)

KTM Enduro R 690 Service Repair Manual / 2012

KTM 690 Enduro R Service Repair Manual 2012 PDF Download
2012 Repair Manuals for Models:
690 Enduro R EU
690 Enduro R AUS/UK
690 Enduro R USA
Article no. 3206125en
File type: PDF
File pages: 234

2012 KTM 690 Enduro R Features and Benefits
– Dynamic LC4 1-cylinder 4-stroke engine, electronic fuel injection, balancer shaft, A PTC anti hopping clutch, 6-speed gearbox,
max. output: 49 kW/67 PS, emissions: Euro 3
– Stainless steel exhaust with catalytic converter
– Ultra-light steel trellis frame, self-supporting plastic tail tank
– New, more comfortable seat with enhanced ergonomics
– New adjustable WP suspension with revised spring rate, optimised front/rear weight distribution and agility
– High quality Brembo braking system
– Extremely low weight of 138 kg
– Sporty 21“/18“ Continental TKC 80 tires perfect for off-road riding
– New, more dynamic spoiler line

ENGINE SINGLE CYLINDER, 4-STROKE ENGINE · DISPLACEMENT 690 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 12L
WEIGHT (READY TO RACE) APPROX. 138.5 KG (WITHOUT FUEL)

KTM DUKE 690 Service Repair Manual / 2012

KTM DUKE 690 Service Repair Manual 2012 PDF Download
Repair Manual 2012 for Models:
690 Duke EU
690 Duke AUS/UK
Article no. 3206123en
File type: PDF
File pages: 208

2012 690 Duke
Manufacturer	KTM
Also called	620/640/690/690 or I/II/III/IV
Production	1994–1997 (I) 1998-2007 (II) 2008–2011 (III) 2012– (IV)
Assembly	Austria
Class	Supermoto or Naked
Engine	609–690 cc (37.2–42.1 cu in) single
Related	640, 690 Enduro

KTM 1190 RC8 R Repair Manual / 2011

KTM 1190 RC8 R Repair Manual 2011 PDF Download
1190 RC8 EU/UK
1190 RC8 AUS
1190 RC8 FR
1190 RC8 JP
1190 RC8 USA
Article no. 3206116en
File type: PDF
File pages: 307

2011 KTM 1190 RC8R – USA Specifications
Engine type 2-cylinder, 4-stroke, V 75°
Displacement 1195 cc
Bore x stroke 105 x 69 mm (4.13 x 2.72″)
Performance (homologated) 129 kW @ 10250 rpm
Max. torque 127 Nm @ 8000 rpm
Compression ratio 13.5:1
Starter/Battery Electric Starter/12 V 11.2 Ah
Transmission 6 gears, dog clutch engagement
Fuel Mixture Generation Keihin EFI (throttle body 52 mm (2.05″))
Control 4 V/DOHC
Lubrication Pressure lubrication with 3 Eaton pumps
Engine lubrication Motorex, SAE 10W-50
Primary drive 40:76
Final drive 17:37
Cooling Liquid cooled
Clutch Wet multi-disc clutch, operated hydraulically
Motor Management Keihin EMS
Frame Chromium-Molybdenum trellis frame, powder-coated
Subframe Aluminium
Handlebar Aluminium stump handlebar
Front suspension WP-USD Ø 43 mm
Rear suspension WP-Monoshock
Suspension travel front/rear 120/120 mm (4.7 / 4.7″)
Front brake 2 x Brembo four piston, radially bolted caliper, brake disc 320 mm (12.6″)
Rear brake Brembo two piston, fixed caliper, brake disc 220 mm (8.66″)
Rims, front/rear Cast aluminium wheels 3.50 x 17”; 6.00 x 17”
Tires, front/rear 120/70 ZR 17; 190/55 ZR 17
Chain X-ring 5/8 x 5/16″
Main silencer Stainless steel underfloor silencer with regulated catalytic converter
Steering head angle 66.7°
Trail 97 mm (3.82″)
Wheel base 1425 mm (56.10″)
Ground clearance (unloaded) 110 mm (4.33″)
Seat height 805/825 mm (31.69/32.48″)
Tank capacity approx. 16.5 liters/3.5 liters reserve (4.36/0.92 gal)
Weight (no fuel) approx. 184 kg (without fuel)

KTM DUKE 125 Service Repair Manual / 2011

KTM DUKE 125 Service Repair Manual 2011 PDF Download
Repair Manual 2011 for Models:
125 Duke EU
125 Duke DE
Article no. 3206110en
File type: PDF
File pages: 195

KTM 125 Duke
KTM 125 Duke hat einen 125-cm3-Einzylinder-Otto-Viertaktmotor, der 11 kW bei 9500 min−1 (15 PS) leistet und ein Drehmoment von 12 N·m bei 8000 min−1 hat. Das Motorrad wurde 2007 in Mattighofen konstruiert und seit 2011 beim indischen KTM-Partner Bajaj Auto in Pune gefertigt.

KTM 990 Supermoto R Service Repair Manual / 2011

KTM 990 Supermoto R Service Repair Manual 2011 PDF Download
2011 Repair Manual Fit Models:
990 Supermoto R EU
990 Supermoto R AUS/UK
990 Supermoto R USA
990 Supermoto R FR
Article no. 3206108en
File type: PDF
File pages: 291

2011 KTM 990 Supermoto R – USA Specifications

ENGINE
Design 2-cylinder 4-stroke Otto motor, 75° V arrangement, water-cooled
Displacement 999 cm³ (60.96 cu in)
Bore 101 mm (3.98 in)
Stroke 62.4 mm (2.457 in)
Performance 85 kW (114 hp)
Cold start device Electric starter
Transmission 6-gears, claw-shifted
Engine lubrication Dry sump lubrication system with two rotor pumps
Primary transmission 35:67
Secondary drive ratio 17:41
Cooling Water cooling, permanent circulation of coolant by water pump
Clutch Multidisc clutch in oil bath/hydraulically activated
Ignition system Contactless controlled fully electronic ignition with digital ignition adjustment

CHASSIS
Frame Lattice frame made of chrome molybdenum steel tubing, powder-coated
Fork WP Suspension Up Side Down 4860 ROMA PA
Shock absorber WP Suspension 4618 BAVP DCC
Suspension travel Front 160 mm (6.3 in)
Suspension travel Rear 180 mm (7.09 in)
Brake system Front Double disc brake with radially screwed four-piston brake calipers, float-mounted brake discs
Brake system Rear Single disc brake with dual-piston brake caliper, rigid-mounted brake disc
Brake discs – diameter Front 305 mm (12.01 in)
Brake discs – diameter Rear 240 mm (9.45 in)
Chain 5/8 x 5/16″ X ring
Steering head angle 65.6°
Wheelbase 1,505±15 mm (59.25±0.59 in)
Ground clearance, unloaded 195 mm (7.68 in)
Seat height, unloaded 875 mm (34.45 in)
Total fuel tank capacity, approx. 15 l (4 US gal)
Super unleaded (ROZ 95/RON 95/PON 91)
Weight without fuel, approx. 189 kg (417 lb.)

KTM 690 SMC Service Repair Manual / 2011

KTM 690 SMC Service Repair Manual 2011 PDF Download
Repair Manual 2011 for Models:
690 SMC EU
690 SMC AUS/UK
Article no. 3206122en
File type: PDF
File pages: 229

2011 KTM 690 SMC – International Specifications
Design Single-cylinder, 4-stroke, spark-ignition engine, liquid-cooled
Displacement 654 cm³ (39.91 cu in)
Bore 102 mm (4.02 in)
Stroke 80 mm (3.15 in)
Performance 46.3 kW (62.1 hp)
Starting aid Electric starter, automatic decompressor
Transmission 6-speed, claw shifted
Engine lubrication Semi-dry-sump lubrication with 2 rotor pumps
Primary gear ratio 36:79
Secondary gear ratio 16:42
Cooling system Liquid cooling system, continuous circulation of cooling liquid with water pump
Clutch APTC™ Anti-hopping clutch / hydraulically operated
Ignition system Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
CHASSIS
Frame Tubular space frame made from chrome molybdenum steel, powder-coated
Forks WP Suspension Up Side Down 4860 ROMA
Shock absorber WP Suspension 4618 with Pro Lever linkage
Suspension travel front 275 mm (10.83 in)
Suspension travel rear 265 mm (10.43 in)
Brake system front Disc brake with radially mounted four-piston brake caliper; floating brake disc
Brake system rear Disc brake with single-piston brake caliper, floating
Brake discs – diameter front 320 mm (12.6 in)
Brake discs – diameter rear 240 mm (9.45 in)
Chain 5/8 x 1/4″ X Ring
Steering head angle 63°
Wheel base 1,480±15 mm (58.27±0.59 in)
Ground clearance (unloaded) 290 mm (11.42 in)
Seat height (unloaded) 910 mm (35.83 in)
Total fuel tank capacity approx. 12 l (3.2 US gal)
Unleaded premium fuel (95 RON)
Weight without fuel approx. 139.5 kg (307.5 lb.)

KTM Enduro 690 Service Repair Manual / 2011

KTM 690 Enduro Service Repair Manual 2011 PDF Download
2011 Repair Manuals for Models:
690 Enduro R EU
690 Enduro R AUS/UK
690 Enduro R USA
Article no. 3206121en
File type: PDF
File pages: 235

KTM 690 Enduro

Manufacturer	KTM
Predecessor	KTM 640 E
Engine	Single cylinder, 4-stroke, 654 cc, Keihin EMS with EPT (Electr. Power Throttle), Pressure lubrication with 2 Eaton pumps
Bore / stroke	102 mm × 80 mm (4.0 in × 3.1 in)
Transmission	6 gears, dog clutch engagement, APTC slipper clutch, hydraulically operated
Frame type	41xx alloy steel trellis frame, powder coated
Brakes	Front: Brembo two piston, floating caliper, 300 mm disc Rear: Brembo single piston, floating caliper, 240 mm disc
Tires	Spoked wheels with aluminium rims 1.85 x 21 / 2.50 x 18, 90/90-21"; 140/80-18"
Rake, trail	63°/115 mm (4.53")
Wheelbase	1498 ± 15 mm (58.98 ± 0.59")
Seat height	910 mm (35.83")
Fuel capacity	12 L (2.6 imp gal; 3.2 US gal) / reserve 2.5 L (0.55 imp gal; 0.66 US gal)
Related	690 Duke

KTM DUKE 690 Service Repair Manual / 2011

KTM DUKE 690 Service Repair Manual 2011 PDF Download
Repair Manual 2011 for Models:
690 Duke EU
690 Duke AUS/UK
690 Duke R EU
690 Duke R AUS/UK
690 Duke R JP
Article no. 3206120en
File type: PDF
File pages: 244

2011 KTM 690 Duke – International Specifications
ENGINE
Design Single-cylinder, 4-stroke, spark-ignition engine, liquid-cooled
Displacement 654 cm³ (39.91 cu in)
Bore 102 mm (4.02 in)
Stroke 80 mm (3.15 in)
Performance 48 kW (64 hp)
Starting aid Electric starter, automatic decompressor
Transmission 6-speed, claw shifted
Engine lubrication Semi-dry-sump lubrication with 2 rotor pumps
Primary gear ratio 36:79
Secondary gear ratio 16:40
Cooling system Liquid cooling system, continuous circulation of cooling liquid with water pump
Clutch APTC™ Anti-hopping clutch / hydraulically operated
Ignition system Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment

CHASSIS
Frame Tubular space frame made from chrome molybdenum steel, powder-coated
Forks WP Suspension Up Side Down 4860 ROMA
Shock absorber WP Suspension 4618 with Pro Lever linkage
Suspension travel front 140 mm (5.51 in)
Suspension travel rear 140 mm (5.51 in)
Brake system front Disc brake with radially mounted four-piston brake caliper; floating brake disc
Brake system rear Disc brake with single-piston brake caliper, floating
Brake discs – diameter front 320 mm (12.6 in)
Brake discs – diameter rear 240 mm (9.45 in)
Chain 5/8 x 1/4″ X Ring
Steering head angle 63.5°
Wheel base 1,472±15 mm (57.95±0.59 in)
Ground clearance (unloaded) 155 mm (6.1 in)
Seat height (unloaded) 865 mm (34.06 in)
Total fuel tank capacity approx. 13.5 l (3.57 US gal)
Unleaded premium fuel (95 RON)
Weight without fuel approx. 148.5 kg (327.4 lb.)
